Timsan was established in İstanbul in 1982 to carry out production of ground support equipment. Timsan has attained ISO 9001:2000 quality assurance system certification in 2002 by means of its production quality and experience.Subsequent to this TSE and CE cerfications has been attained for products one by one.
The progression which was started with Turkish Airlines, İstanbul Airlines, Çelebi, Havaş just in Turkey in 1982, is being improved in these by exportations to 30 agents in 41 countries in Europe, Asia and Africa.
Our firm carries out design, production, quality control, sales, and service/maintance after sales of more then 40 ground support vehicles and lots of equipments in Airport Sector and Ground Support Vehicles Production Sector which includes; palet and container dollies, baggage trailers, conveyors, passenger stairs, ambulance truck, catering truck, water and lavatory trucks, de-icing truck, maintenance platform, loader,air traffic control tower, aircraft & cargo tow tractors.
In 1988, Construction firm of Timsan has been established as subsidiary company for constructions of industrial buildings in a turnkey manner.Since then The firm has been carried out more then 30 factory buildings and 4 hangar constructions.
Our third firm which was established in 1994 which serves to our customers for some kind of ground support vehicles which we do not produce. Besides, our fourth firm established in 2010 for to produce aircraft and cargo tow tractors.
Timsan has achieved being well known mark all around the world by its staff, as 110 employees and more then 1000 subcontractors, and suppliers.
|
CHASSIS |
The chassis is produced by steel profiles and the platform floor is covered with steel sheets. |
|
STEERING & BRAKING SYS. |
The tow-bar is provided by a fifth wheel system mounted to the chassis for easy steering. Front wheel maneuvering is provided by a slewing ring that works vertically on the axis. The steering system equipped with a brake system that is applied when tow-bar is upright and released position. |
|
SURFACES |
The chassis is hot-dip galvanized. |
|
OPTIONS |
Side barriers, tarpadin and tarpadin basket, plywood platform and railings, custom painting, spare wheel. |
|
CHASSIS |
The chassis is produced by steel profiles and the platform floor is covered with steel sheets. |
|
STEERING & BRAKING SYS. |
The tow-bar is provided by a fifth wheel system mounted to the chassis for easy steering. Front wheel maneuvering is provided by a slewing ring that works vertically on the axis. The steering system equipped with a brake system that is applied when tow-bar is upright and released position. |
|
SURFACES |
The chassis is hot-dip galvanized. |
|
OPTIONS |
Side barriers, tarpadin and tarpadin basket, plywood platform and railings, custom painting, spare wheel. |
|
CHASSIS |
The chassis is produced by steel profiles and the platform floor is covered with steel sheets. |
|
STEERING & BRAKING SYS. |
The tow-bar is provided by a fifth wheel system mounted to the chassis for easy steering. Front wheel maneuvering is provided by a slewing ring that works vertically on the axis. The steering system equipped with a brake system that is applied when tow-bar is upright and released position. |
|
SURFACES |
The chassis is hot-dip galvanized. |
|
OPTIONS |
Side barriers, tarpadin and tarpadin basket, plywood platform and railings, custom painting, spare wheel. |
|
CHASSIS |
The chassis consists of two main parts as lower and upper chassis which are made of steel and provide 360° rotation via turntable and have four locking positions at every 90°. The walkway is covered with bored steel sheet to prevent slipping and provides drainage. |
|
STEERING & BRAKING SYS. |
The tow-bar is provided by a fifth wheel system mounted to the chassis for easy steering. Front wheel maneuvering is provided by a slewing ring that works vertically on the axis. The steering system equipped with a brake system that is applied when tow-bar is upright and released position. |
|
ROLLERS |
The rollers are made of 2” galvanized pipes with bearings at both ends. The rollers are easily replaceable. |
|
GUIDE RAILS |
The both sides of the upper chassis are provided by guide rails made of steel sheet to prevent the load from falling off. |
|
STOPS |
The upper chassis provides two manually operated special retractable stops which can be controlled from both sides of the upper chassis used to restrain containers firmly. |
|
SURFACES |
The chassis is hot-dip galvanized. |
|
OPTIONS |
Stop for LD2, custom painting, upper chassis made of box profiles, spare wheel. |
|
CHASSIS |
The chassis is produced by steel profiles. The walkway is covered with bored steel sheet to prevent slipping and provides drainage. The PD7000 is side-towed and end-loaded and PD14000 is end-towed and end-loaded. |
|
STEERING & BRAKING SYS. |
The mobility of the unit is provided by fixed rear wheels and 360° swivel type front wheels which ensure high maneuverability capacity. The rear wheels are equipped with a brake system that is applied when tow-bar is upright position. |
|
ROLLERS |
The rollers are produced by 2 ½” galvanized pipes with bearings at both ends arranged in an order of two rows to ensure easy operations of the pallet. |
|
GUIDE RAILS |
The both sides of the upper chassis provide adequate guide rails made of steel sheet to prevent the load from falling off. |
|
STOPS |
The upper chassis provides special retractable stops made of steel sheet to be used to restrain containers firmly. |
|
SURFACES |
The chassis is hot-dip galvanized. |
|
OPTIONS |
Stops for P2 (PD7000) Stops for P1-P2-P4-P6 (PD14000) Custom painting, three rows of rollers, four rows of rollers, turntable for loading platform (PD7000), spare wheel. |
|
CHASSIS |
The chassis is produced by steel profiles. The walkway is covered with bored steel sheet to prevent slipping and provides drainage. The PD7000 is side-towed and end-loaded and PD14000 is end-towed and end-loaded. |
|
STEERING & BRAKING SYS. |
The mobility of the unit is provided by fixed rear wheels and 360° swivel type front wheels which ensure high maneuverability capacity. The rear wheels are equipped with a brake system that is applied when tow-bar is upright position. |
|
ROLLERS |
The rollers are produced by 2 ½” galvanized pipes with bearings at both ends arranged in an order of two rows to ensure easy operations of the pallet. |
|
GUIDE RAILS |
The both sides of the upper chassis provide adequate guide rails made of steel sheet to prevent the load from falling off. |
|
STOPS |
The upper chassis provides special retractable stops made of steel sheet to be used to restrain containers firmly. |
|
SURFACES |
The chassis is hot-dip galvanized. |
|
OPTIONS |
Stops for P2 (PD7000) Stops for P1-P2-P4-P6 (PD14000) Custom painting, three rows of rollers, four rows of rollers, turntable for loading platform (PD7000), spare wheel. |
|
CHASSIS |
The chassis is produced by steel profiles. The tow-bar is provided by a fifth wheel system mounted to the chassis for easy steering and a brake system that is applied when tow-bar is upright and released position. |
|
CONVEYOR |
The conveyor boom provides adequate number of rollers to support the belt and safe conveyance of load. The belt forward/reverse movements are provided by hydraulic motor and the height and angle adjustment are provided by hydraulic cylinders. The conveyor boom provides foldable handrail. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a pump driven by an engine, cylinders, hydro-motor, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of engine failure. |
|
SURFACES |
The belt conveyor is custom painted. |
|
ELECTRICAL SYSTEM |
The electrical system is powered by a standard battery of 12 V DC. The electrical system is provided by headlamp and the all accessories are controlled from a control panel. |
|
OPTIONS |
9000 mm belt length, electrical emergency pump, diesel engine, hydro-static propelling system powered by hydraulic motor, forklift pockets, custom painting, logo application. |
|
CHASSIS |
The chassis is produced by steel profiles. The tow-bar is provided by a fifth wheel system mounted to the chassis for easy steering and a brake system that is applied when tow-bar is upright and released position. |
|
CONVEYOR |
The conveyor boom provides adequate number of rollers to support the belt and safe conveyance of load. The belt forward/reverse movements are provided by hydraulic motor and the height and angle adjustment are provided by hydraulic cylinders. The conveyor boom provides foldable handrail. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a pump driven by an engine, cylinders, hydro-motor, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of engine failure. |
|
SURFACES |
The belt conveyor is custom painted. |
|
ELECTRICAL SYSTEM |
The electrical system is powered by a standard battery of 12 V DC. The electrical system is provided by headlamp and the all accessories are controlled from a control panel. |
|
OPTIONS |
9000 mm belt length, electrical emergency pump, diesel engine, hydro-static propelling system powered by hydraulic motor, forklift pockets, custom painting, logo application. |
|
CHASSIS |
The chassis is designed by Timsan, produced by steel plates and powered by diesel engine with automatic transmission. |
|
CONVEYOR |
The conveyor boom provides adequate number of rollers to support the belt and safe conveyance of load. The belt forward/reverse movements are provided by hydraulic motor and the height and angle adjustment are provided by hydraulic cylinders. The conveyor boom provides foldable handrail. |
|
TRACTION SYSTEM |
The traction system is provided by a diesel engine with an electrically controlled power-shift transmission with torque converter. Hydraulic assisted double circuit braking system with disc brakes is provided. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a pump driven by an engine, cylinders, hydraulic motor, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of engine failure. |
|
SURFACES |
The belt conveyor is custom painted. |
|
ELECTRICAL SYSTEM |
The electrical system is powered by a standard battery of 12 V DC. The electrical system is provided by work lamp, automatic starter, standard lighting for chassis and the all accessories are controlled from a control panel. |
|
OPTIONS |
9000 mm belt length, electrical emergency pump, different brand of diesel engine and transmission, forklift pockets, custom painting, logo application. |
|
CHASSIS |
The chassis is produced by steel profiles and mounted on a commercial truck. |
|
CONVEYOR |
The conveyor boom provides adequate number of rollers to support the belt and safe conveyance of load. The belt forward/reverse movements are provided by hydraulic motor and the height and angle adjustment are provided by hydraulic cylinders. One of the side handrails is foldable and the other one is fixed. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a pump driven by an engine, cylinders, hydraulic motor, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of engine failure. |
|
SURFACES |
The belt conveyor is custom painted. |
|
ELECTRICAL SYSTEM |
The electrical system is powered by a standard battery of 12 V DC. The electrical system is provided by work lamp, automatic starter, standard lighting for chassis and the all accessories are controlled from a control panel. |
|
OPTIONS |
9000 mm belt length, electrical emergency pump, custom painting, logo application. |
|
CHASSIS |
The chassis is designed by Timsan, produced by steel plates and powered by electric motor. |
|
CONVEYOR |
The conveyor boom provides adequate number of rollers to support the belt and safe conveyance of load. The belt forward/reverse movements are provided by hydraulic motor and the height and angle adjustment are provided by hydraulic cylinders. Fixed and foldable handrails are provided on the conveyor boom. |
|
TRACTION SYSTEM |
The traction system is provided by an 80 V AC electric motor powered with 80 V DC battery pack and controlled by high efficiency AC controller with regenerative braking system. Hydraulic assisted double circuit braking system with disc brakes is provided. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a pump driven by an electric motor, cylinders, hydraulic motor, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of system failure. |
|
SURFACES |
The conveyor boom is hot dip galvanized. |
|
ELECTRICAL SYSTEM |
Work lamp, standard lighting for chassis, are provided in electrical system. All functions and accessories are controlled from control panels located on the driver’s cluster and on the both sides in the front and rear of the conveyor boom. |
|
OPTIONS |
9000 mm belt length, different capacity of battery pack, forklift pockets, custom painting, logo application, driver’s cabin. |
|
CHASSIS |
The chassis is produced by steel profiles and stable against wind forces up to 75 km/h. The tow-bar is provided by a fifth wheel system mounted to the chassis for easy steering and a brake system that is applied when tow-bar is upright and released position. |
|
STAIRWAY |
TPS 4500/5800 are provided by telescopic steps and TPS 3800 is provided by parallelogram steps. Sidewalls and steps are covered by aluminum and checkered aluminum respectively. |
|
PLATFORM |
The platform is produced by steel profiles and its floor is covered by checkered aluminum. Side panels are retractable. The platform and side panels provide bumpers in order to prevent giving any damage to fuselage. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a hydraulic pump driven by an engine, cylinders used for lifting/telescoping, lock valves, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of engine failure. |
|
STABILIZERS |
The stair is provided by 4 hydraulic stabilizers with lock valves. |
|
SURFACES |
The chassis, stairway and platform are custom painted. |
|
ELECTRICAL SYSTEM |
The electrical system is powered by a standard battery of 12 V DC min. 90 Ah. The electrical system is provided by two rear lamps, stair illumination lamps, adjustable headlamp and a beacon. The all accessories are controlled from a control panel. |
|
OPTIONS |
Canopy, electrical emergency pump, diesel engine, single wheel hydro-static propelling system powered by hydraulic motor, forklift pockets, custom painting, logo application, spare wheel. |
|
CHASSIS |
The chassis is produced by steel profiles and stable against wind forces up to 75 km/h. The tow-bar is provided by a fifth wheel system mounted to the chassis for easy steering and a brake system that is applied when tow-bar is upright and released position. |
|
STAIRWAY |
TPS 4500/5800 are provided by telescopic steps and TPS 3800 is provided by parallelogram steps. Sidewalls and steps are covered by aluminum and checkered aluminum respectively. |
|
PLATFORM |
The platform is produced by steel profiles and its floor is covered by checkered aluminum. Side panels are retractable. The platform and side panels provide bumpers in order to prevent giving any damage to fuselage. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a hydraulic pump driven by an engine, cylinders used for lifting/telescoping, lock valves, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of engine failure. |
|
STABILIZERS |
The stair is provided by 4 hydraulic stabilizers with lock valves. |
|
SURFACES |
The chassis, stairway and platform are custom painted. |
|
ELECTRICAL SYSTEM |
The electrical system is powered by a standard battery of 12 V DC min. 90 Ah. The electrical system is provided by two rear lamps, stair illumination lamps, adjustable headlamp and a beacon. The all accessories are controlled from a control panel. |
|
OPTIONS |
Canopy, electrical emergency pump, diesel engine, single wheel hydro-static propelling system powered by hydraulic motor, forklift pockets, custom painting, logo application, spare wheel. |
|
CHASSIS |
The chassis is produced by steel profiles mounted on a commercial truck according to the customer’s demand. The all stairs are stable against wind forces up to 75 km/h. |
|
STAIRWAY |
Stairways are provided by telescopic steps. Sidewalls and steps are covered by aluminum and checkered aluminum respectively. |
|
PLATFORM |
The platform is produced by steel profiles and its floor is covered by checkered aluminum. Side panels are retractable. The platform and side panels provide bumpers in order to prevent giving any damage to fuselage. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a hydraulic pump driven by engine, cylinders used for lifting/telescoping, lock valves, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of engine failure. |
|
STABILIZERS |
The stair is provided by 4 hydraulic stabilizers with lock valves. |
|
SURFACES |
The chassis, stairway and platform are custom painted. |
|
ELECTRICAL SYSTEM |
The electrical system is powered by a standard battery of the truck. The electrical system is provided by two rear lamps, stair illumination lamps, adjustable headlamp, standard lighting for chassis and a beacon. The all operations are controlled from a control panel. |
|
OPTIONS |
1500 mm stair width, canopy, electrical emergency pump, custom painting, logo application, spare wheel. |
|
CHASSIS |
The chassis is designed by Timsan, produced by steel profiles and plates. The all stairs are stable against wind forces up to 75 km/h. |
|
STAIRWAY |
Stairways are provided by telescopic steps. Sidewalls and steps are covered by aluminum and checkered aluminum respectively. |
|
PLATFORM |
The platform is produced by steel profiles and its floor is covered by checkered aluminum. Side panels are retractable. The platform and side panels provide bumpers in order to prevent giving any damage to fuselage. |
|
TRACTION SYSTEM |
For diesel engine stairs ; the traction system is provided by a diesel engine with an electrically controlled power-shift transmission with torque converter. The both type have hydraulic assisted double circuit braking system with disc brakes. For battery powered stairs ; the traction system is provided by an 80 V AC electric motor powered with 80 V DC battery pack and controlled by high efficiency AC controller with regenerative braking system. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a hydraulic pump driven by engine, cylinders used for lifting/telescoping, lock valves, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of engine failure. |
|
STABILIZERS |
The stair is provided by 4 hydraulic stabilizers with lock valves. |
|
SURFACES |
The chassis, stairway and platform are custom painted. |
|
ELECTRICAL SYSTEM |
The electrical system is provided by two rear lamps, stair illumination lamps, adjustable headlamp, standard lighting for chassis and a beacon. The all accessories are controlled from a control panel. |
|
OPTIONS |
1500 mm stair width, driver’s cabin, canopy, electrical emergency pump, custom painting, logo application, spare wheel. |
|
CHASSIS |
The chassis is designed by Timsan, produced by steel profiles and plates. The all stairs are stable against wind forces up to 75 km/h. |
|
STAIRWAY |
Stairways are provided by telescopic steps. Sidewalls and steps are covered by aluminum and checkered aluminum respectively. |
|
PLATFORM |
The platform is produced by steel profiles and its floor is covered by checkered aluminum. Side panels are retractable. The platform and side panels provide bumpers in order to prevent giving any damage to fuselage. |
|
TRACTION SYSTEM |
For diesel engine stairs ; the traction system is provided by a diesel engine with an electrically controlled power-shift transmission with torque converter. The both type have hydraulic assisted double circuit braking system with disc brakes. For battery powered stairs ; the traction system is provided by an 80 V AC electric motor powered with 80 V DC battery pack and controlled by high efficiency AC controller with regenerative braking system. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a hydraulic pump driven by engine, cylinders used for lifting/telescoping, lock valves, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of engine failure. |
|
STABILIZERS |
The stair is provided by 4 hydraulic stabilizers with lock valves. |
|
SURFACES |
The chassis, stairway and platform are custom painted. |
|
ELECTRICAL SYSTEM |
The electrical system is provided by two rear lamps, stair illumination lamps, adjustable headlamp, standard lighting for chassis and a beacon. The all accessories are controlled from a control panel. |
|
OPTIONS |
1500 mm stair width, driver’s cabin, canopy, electrical emergency pump, custom painting, logo application, spare wheel. |
|
CHASSIS |
The chassis is produced by steel profiles and steel plates. |
|
STEERING & BRAKING SYS. |
The tow-bar is provided by a fifth wheel system mounted to the chassis for easy steering. Front wheel maneuvering is provided by a slewing ring that works vertically on the axis. The steering system equipped with a brake system that is applied when tow-bar is at upright and released position. |
|
TANK |
The tanks are made of stainless steel and provided by manholes, filler caps and discharge valves. The top of the tanks are covered with anti slip material or steel grid for safe walking. |
|
CLEAN WATER PUMP |
The clean water pump is driven by hydro-motor, which is powered by the diesel engine or electric motor, to be used to pump the clean water to aircraft’s tank. |
|
WASTE WATER COUPLING |
The waste water coupling is made of stainless steel and is of quick coupling type. It is equipped with 4” flexible hose. |
|
CLEAN WATER COUPLING |
The waste water coupling is made of stainless steel and is of quick coupling type. It is equipped with 1” flexible hose. |
|
ELECTRICAL SYSTEM |
The electrical system is powered by a standard battery pack. The electrical system is provided by work lamp and the all accessories are controlled from a control panel. |
|
ELEVATING LADDER |
A foldable ladder is provided to be used for operator to reach desired elevating height to serve aircraft. |
|
SURFACES |
The all parts are custom painted. |
|
OPTIONS |
heating, insulation, vacuum pump, logo application. |
|
CHASSIS |
The chassis is produced by steel profiles and mounted on a commercial truck. |
|
TANK |
The tanks are made of stainless steel and provided by manholes, filler caps and discharge valves. The top of the tanks are covered with anti slip material or steel grid for safe walking. |
|
CLEAN WATER PUMP |
The clean water pump is driven by hydro-motor, which is powered by the diesel engine, to be used to pump the clean water to aircraft’s tank. |
|
WASTE WATER COUPLING |
The waste water coupling is made of stainless steel and is of quick coupling type. It is equipped with 4” flexible hose. |
|
CLEAN WATER COUPLING |
The waste water coupling is made of stainless steel and is of quick coupling type. It is equipped with 1” flexible hose. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a pump driven by an engine, hydro-motor, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of engine failure. |
|
ELECTRICAL SYSTEM |
The electrical system is powered by a standard battery of truck. The electrical system is provided by work lamp and the all accessories are controlled from a control panel. |
|
ELEVATING PLATFORM |
A hydraulic powered work platform is provided to be used for operator to reach desired elevating height to serve aircraft. |
|
SURFACES |
The all parts are custom painted. |
|
OPTIONS |
Electrical emergency pump, articulated ladder, heating, insulation, vacuum pump, logo application. |
|
CHASSIS |
The chassis is produced by steel profiles and mounted on a commercial truck. |
|
TANK |
The tanks are made of stainless steel and provided by manholes, filler caps and discharge valves. The top of the tanks are covered with anti slip material or steel grid for safe walking. |
|
CLEAN WATER PUMP |
The clean water pump is driven by hydro-motor, which is powered by the diesel engine, to be used to pump the clean water to aircraft’s tank. |
|
WASTE WATER COUPLING |
The waste water coupling is made of stainless steel and is of quick coupling type. It is equipped with 4” flexible hose. |
|
CLEAN WATER COUPLING |
The waste water coupling is made of stainless steel and is of quick coupling type. It is equipped with 1” flexible hose. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a pump driven by an engine, hydro-motor, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of engine failure. |
|
ELECTRICAL SYSTEM |
The electrical system is powered by a standard battery of truck. The electrical system is provided by work lamp and the all accessories are controlled from a control panel. |
|
ELEVATING PLATFORM |
A hydraulic powered work platform is provided to be used for operator to reach desired elevating height to serve aircraft. |
|
SURFACES |
The all parts are custom painted. |
|
OPTIONS |
Electrical emergency pump, articulated ladder, heating, insulation, vacuum pump, logo application. |
|
CHASSIS |
The chassis is designed by Timsan, produced by steel profiles and powered by diesel engine with electrically controlled power-shift transmission with torque converter. |
|
TANK |
The tanks are made of stainless steel and provided by manholes, filler caps and discharge valves. The top of the tanks are covered with anti slip material or steel grid for safe walking. |
|
CLEAN WATER PUMP |
The clean water pump is driven by hydro-motor, which is powered by the diesel engine, to be used to pump the clean water to aircraft’s tank. |
|
WASTE WATER COUPLING |
The waste water coupling is made of stainless steel and is of quick coupling type. It is equipped with 4” flexible hose. |
|
CLEAN WATER COUPLING |
The waste water coupling is made of stainless steel and is of quick coupling type. It is equipped with 1” flexible hose. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a pump driven by an engine, hydro-motor, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of engine failure. |
|
ELECTRICAL SYSTEM |
The electrical system is powered by a standard battery of engine. The electrical system is provided by work lamp and the all accessories are controlled from a control panel. |
|
ELEVATING PLATFORM |
A hydraulic powered work platform is provided to be used for operator to reach desired elevating height to serve aircraft. |
|
SURFACES |
The all parts are custom painted. |
|
OPTIONS |
Electrical emergency pump, articulated ladder, different brand of diesel engine and transmission, heating, insulation, vacuum pump, logo application. |
|
CHASSIS |
The chassis is designed by Timsan, produced by steel profiles and powered by diesel engine with electrically controlled power-shift transmission with torque converter. |
|
TANK |
The tanks are made of stainless steel and provided by manholes, filler caps and discharge valves. The top of the tanks are covered with anti slip material or steel grid for safe walking. |
|
CLEAN WATER PUMP |
The clean water pump is driven by hydro-motor, which is powered by the diesel engine, to be used to pump the clean water to aircraft’s tank. |
|
WASTE WATER COUPLING |
The waste water coupling is made of stainless steel and is of quick coupling type. It is equipped with 4” flexible hose. |
|
CLEAN WATER COUPLING |
The waste water coupling is made of stainless steel and is of quick coupling type. It is equipped with 1” flexible hose. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a pump driven by an engine, hydro-motor, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of engine failure. |
|
ELECTRICAL SYSTEM |
The electrical system is powered by a standard battery of engine. The electrical system is provided by work lamp and the all accessories are controlled from a control panel. |
|
ELEVATING PLATFORM |
A hydraulic powered work platform is provided to be used for operator to reach desired elevating height to serve aircraft. |
|
SURFACES |
The all parts are custom painted. |
|
OPTIONS |
Electrical emergency pump, articulated ladder, different brand of diesel engine and transmission, heating, insulation, vacuum pump, logo application. |
|
VAN BODY |
The steel constructed body is covered with insulation material filled polyester plates. The van-body is lifted by a scissors system powered by two single acting telescopic hydraulic cylinders. The van-body provides a lock system for 50 ea. trolleys mounted on the side walls. Adequate ventilation is provided inside the van body. Front/rear roller doors are provided on the van body. A control panel is provided on the front part of the van body which has a side door. |
|
FRONT PLATFORM |
The front platform is produced by steel profiles and is hot dip galvanized. It moves with van body to serve the aircraft. The front platform provides an extendible part moved by a hydraulic cylinder and the front platform moves longitudinally along the van body for a better alignment to the aircraft door. The floor is covered with checkered aluminum. A heavy duty canopy is provided on the front platform which covers the front platform and the aircraft door completely. |
|
TRUCK |
Subject to customer’s demand. Min. GVW is 25.000 kg. |
|
STABILIZING SYSTEM |
The stabilizing system is composed of 4 vertically and 4 horizontally operated hydraulic cylinder. Gear type flow-divider is used to operate stabilizers simultaneously. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a pump driven by truck engine, cylinders, lock valves, hydraulic valves and some useful accessories. Emergency hand pump and a power-pack are also used in case of engine failure. |
|
SURFACES |
The platform and the tail lift is hot dip galvanized and the other parts are custom painted. |
|
LIGHTING |
8 LED type lighting fixtures, headlamps in front and rear of the platform, gabary lamps at the corners and a beacon are provided on the van body. |
|
OPTIONS |
Tail lift, cooling system for van body and the driver cab, emergency stair, custom painting, logo application. |
|
VAN BODY |
The steel constructed body is covered with insulation material filled polyester plates. The van-body is lifted by a scissors system powered by two single acting telescopic hydraulic cylinders. The van-body provides a lock system for trolleys mounted the side walls. Adequate ventilation is provided inside the van body. The van body provides front/rear roller doors. |
|
FRONT PLATFORM |
The front platform is produced by steel profiles and is hot dip galvanized. It moves with van body to serve the aircraft. The front platform provides an extendible part moved by a hydraulic cylinder and an access bridge which moves longitudinally along the front platform. The floor is covered with checkered aluminum. |
|
TRUCK |
Subject to customer’s demand. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a pump driven by truck engine, cylinders, lock valves, hydraulic valves and some useful accessories. Emergency hand pump is also used in case of engine failure. 4 hydraulic stabilizers are provided for more stability. |
|
SURFACES |
The platform and the tail lift is hot dip galvanized and the other parts are custom painted. |
|
LIGHTING |
LED type lighting fixtures, headlamps in front and rear of the platform, gabary lamps at the corners and a beacon are provided on the van body. |
|
OPTIONS |
Tail lift, canopy, electrical emergency pump, cooling system for van body and the driver cab, side door, emergency stair, custom painting, logo application. |
|
VAN BODY |
The steel constructed body is covered with insulation material filled polyester plates. The van-body is lifted by a scissors system powered by two single acting hydraulic cylinders. The van-body provides a lock system for wheelchairs and stretchers. Adequate ventilation is provided inside the van body and windows are provided on the both side walls. The van body provides double winged doors with sight glass at rear and a single door at front, leading to the front platform. |
|
FRONT PLATFORM |
The front platform is produced by steel profiles and moves with van body to serve the aircraft. The front platform provides an extendible part moved by a hydraulic cylinder. The floor is covered with checkered aluminum. Two independent platforms are provided in the half cab applications. |
|
TRUCK |
Subject to customer’s demand. |
|
TAIL LIFT |
The van body is provided by a foldable tail lift produced by steel profiles and powered by a hydraulic cylinder via chain-pulley system to be used to carry wheelchair or stretcher and their attendant. The floor is covered with checkered aluminum and provides a ramp to aid wheelchair loading and handrails for safety. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a pump driven by truck engine, cylinders, lock valves, hydraulic valves and some useful accessories. Emergency hand pump is also used in case of engine failure. 4 hydraulic stabilizers are provided for more stability. |
|
SURFACES |
The platform and the tail lift is hot dip galvanized and the other parts are custom painted. |
|
LIGHTING |
LED type lighting fixtures, headlamps in front and rear of the platform, gabary lamps at the corners and a beacon are provided on the van body. |
|
OPTIONS |
Canopy, electrical emergency pump, heating and cooling system for van body and the driver cab, side door, emergency stair, custom painting, logo application. |
|
VAN BODY |
The steel constructed body is covered with insulation material filled aluminum plates. The van-body is lifted by a two stage mast lifting system powered by hydraulic cylinders. The van-body provides a lock system for wheelchairs and stretchers. Adequate ventilation is provided inside the van body and windows are provided on the both side walls. |
|
EXTENDABLE FRONT PLATFORM |
The extendable front platform is produced by steel profiles and moves with van body to serve the aircraft. The extendable front platform provides an extension by a hydraulic cylinder. The floor is covered with checkered aluminum. |
|
CHASSIS |
The chassis is designed by Timsan, produced by steel plates and powered by electric traction motors. The unit is stable against wind forces up to 75 km/h. |
|
TRACTION&STEERING SYSTEM |
The traction system is provided by dual direct drive 2x5 kW AC electric motors coupled to planetary wheel hub and powered by 48 V 565 Ah traction battery pack. The electric motors are driven by high efficiency AC controller that enables regenerative braking system. The steering system is controlled by a an electrical system mounted to the steering wheel that controls electric motors which drives the gears of the wheel hub. |
|
CONTROL SYSTEM |
An accelerator and a braking pedal are provided o the driver’s panel which controls the traction system. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, hydraulic pump motor, cylinders, lock valves, hydraulic valves, gear type flow divider for stabilizers and some useful accessories. Emergency hand pump is also used in case of engine failure. 4 hydraulic stabilizers are provided for more stability. |
|
SURFACES |
The platform is hot dip galvanized and the other parts are custom painted. |
|
LIGHTING |
4 lighting fixtures and headlamps in front and rear of the platform, gabary lamps at the corners and a beacon are provided on the van body. |
|
OPTIONS |
Canopy for front platform, heating and cooling system for van body, custom painting, logo application. |
|
PLATFORM |
The platform is produced by steel profiles and covered with checkered aluminum or steel plates. The platform provides steel pipe handrails. The raising and lowering of the platform is provided by hydraulic cylinders. |
|
TRUCK |
Subject to customer’s demand. |
|
STABILIZERS |
4 qty. of vertical hydraulic stabilizers are provided for MSP 7000/10000 and horizontal-vertical stabilizers are provided for MSP 13000 for more stability. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a pump driven by truck engine, cylinders, lock valves, hydraulic valves and some useful accessories. Emergency hand pump is also used in case of engine failure |
|
SURFACES |
The all parts are custom painted. |
|
LIGHTING |
The platform is equipped with 2 headlamps. |
|
OPTIONS |
Electrical emergency pump, logo application, automatic start/stop function on the platform. |
|
CHASSIS: |
The steel constructed chassis is mounted on a commercial truck. |
|
VAN BODY: |
The frame of the van body is constructed from steel box hollow profiles and covered with hot-dip galvanized steel sheet. The equipments inside the van body are ease accessible via locked doors. |
|
ACCESS PLATFORM: |
There is an access platform on the top of the van body to be used in de/anti-icing operations which has a horizontal outreach. This platform is hydraulically powered and controlled by an electrical system. The cage of the platform is equipped with nozzles for de/anti-icing and working projector for night operations. |
|
HYDRAULIC SYSTEM:
|
The access platform and de/anti-icing system is powered by hydraulic system. The hydraulic pump, driven by truck engine via PTO, provides enough oil pressure and flow to the system. Hydraulic oil is controlled by valve block which is energized by electrically. Safety relief valves are used to protect the system. |
|
ELECTRICAL SYSTEM:
|
12-24 V DC electrical system is used to control all systems. There are two electrical control panels; main panel, mounted on the van body and control panel on the cage of the platform. The power supply of the electrical system is the battery, charged by truck engine. |
|
DE/ANTI-ICING SYSTEM: |
The de/anti-icing system is powered by two special pumps separately driven by hydraulic system. There are five selectable mixture levels for all kinds of applications. De/anti-icing fluids are stored in stainless steel tanks and heated by a diesel blower to increase the effect of the applications. |
|
OPTIONS |
Different capacities of tank and pumps, different brand of truck and generator, different working height of access platform, remote communication system. |
|
CHASSIS: |
The steel constructed chassis is enough durable to withstand the torsion of the access platform. The chassis is towable via front axle which has a fifth wheel for ease of steering. Parking brake is activated from the tow-bar. |
|
VAN BODY: |
The frame of the van body is constructed from steel box hollow profiles and covered with hot-dip galvanized steel sheet. The equipments inside the van body are ease accessible via locked doors. A walkway with hand railings is designed for ease accessible for the access platform. A ladder is mounted at back side of the van body to access to the walkway. The floor of the walkway is covered with checkered aluminum plates. |
|
ACCESS PLATFORM: |
There is an access platform on the top of the van body to be used in de/anti-icing operations. This platform is hydraulically powered and controlled by an electrical system. The cage of the platform is equipped with nozzles for de/anti-icing and working projector for night operations. |
|
HYDRAULIC SYSTEM:
|
The access platform and de/anti-icing system is powered by hydraulic system. The tandem hydraulic pump, driven by diesel engine, provides enough oil pressure and flow to the system. Hydraulic oil is controlled by valve block which is energized by electrically. Safety relief valves are used to protect the system. |
|
ELECTRICAL SYSTEM:
|
12 V DC electrical system is used to control all systems. There are two electrical control panels; main panel, mounted on the van body and control panel on the cage of the platform. The power supply of the electrical system is the battery, charged by diesel engine. |
|
DE/ANTI-ICING SYSTEM: |
The de/anti-icing system is powered by two special pumps separately driven by hydraulic system. There are five selectable mixture levels for all kinds of applications. De/anti-icing fluids are stored in stainless steel tanks and heated by a diesel blower to increase the effect of the applications. |
|
OPTIONS |
Different capacities of tank and pumps, different brand of diesel engine and generator, Different working height of access platform, remote communication system. |
|
CHASSIS: |
The steel constructed chassis is mounted on a commercial truck. |
|
VAN BODY: |
The frame of the van body is constructed from steel box hollow profiles and covered with hot-dip galvanized steel sheet. The equipments inside the van body are ease accessible via locked doors. |
|
ACCESS PLATFORM: |
There is an access platform on the top of the van body to be used in de/anti-icing operations which has a horizontal outreach. This platform is hydraulically powered and controlled by an electrical system. The cage of the platform is equipped with nozzles for de/anti-icing and working projector for night operations. |
|
HYDRAULIC SYSTEM:
|
The access platform and de/anti-icing system is powered by hydraulic system. The hydraulic pump, driven by truck engine via PTO, provides enough oil pressure and flow to the system. Hydraulic oil is controlled by valve block which is energized by electrically. Safety relief valves are used to protect the system. |
|
ELECTRICAL SYSTEM:
|
12-24 V DC electrical system is used to control all systems. There are two electrical control panels; main panel, mounted on the van body and control panel on the cage of the platform. The power supply of the electrical system is the battery, charged by truck engine. |
|
DE/ANTI-ICING SYSTEM: |
The de/anti-icing system is powered by two special pumps separately driven by hydraulic system. There are five selectable mixture levels for all kinds of applications. De/anti-icing fluids are stored in stainless steel tanks and heated by a diesel blower to increase the effect of the applications. |
|
OPTIONS |
Different capacities of tank and pumps, different brand of truck and generator, different working height of access platform, remote communication system. |
|
CHASSIS |
The chassis is designed by Timsan, produced by steel profiles and plates. The all stairs are stable against wind forces up to 75 km/h. |
|
STAIRWAY |
Stairways are provided by telescopic steps. Sidewalls and steps are covered by aluminum and checkered aluminum respectively. |
|
PLATFORM |
The platform is produced by steel profiles and its floor is covered by checkered aluminum. Side panels are retractable. The platform and side panels provide bumpers in order to prevent giving any damage to fuselage. |
|
TRACTION SYSTEM |
For diesel engine stairs ; the traction system is provided by a diesel engine with an electrically controlled power-shift transmission with torque converter. The both type have hydraulic assisted double circuit braking system with disc brakes. For battery powered stairs ; the traction system is provided by an 80 V AC electric motor powered with 80 V DC battery pack and controlled by high efficiency AC controller with regenerative braking system. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a hydraulic pump driven by engine, cylinders used for lifting/telescoping, lock valves, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of engine failure. |
|
STABILIZERS |
The stair is provided by 4 hydraulic stabilizers with lock valves. |
|
SURFACES |
The chassis, stairway and platform are custom painted. |
|
ELECTRICAL SYSTEM |
The electrical system is provided by two rear lamps, stair illumination lamps, adjustable headlamp, standard lighting for chassis and a beacon. The all accessories are controlled from a control panel. |
|
OPTIONS |
1500 mm stair width, driver’s cabin, canopy, electrical emergency pump, custom painting, logo application, spare wheel. |
|
CHASSIS |
The chassis is designed by Timsan, produced by steel plates and powered by electric motor. |
|
CONVEYOR |
The conveyor boom provides adequate number of rollers to support the belt and safe conveyance of load. The belt forward/reverse movements are provided by hydraulic motor and the height and angle adjustment are provided by hydraulic cylinders. Fixed and foldable handrails are provided on the conveyor boom. |
|
TRACTION SYSTEM |
The traction system is provided by an 80 V AC electric motor powered with 80 V DC battery pack and controlled by high efficiency AC controller with regenerative braking system. Hydraulic assisted double circuit braking system with disc brakes is provided. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, a pump driven by an electric motor, cylinders, hydraulic motor, hydraulic valves and some other useful accessories. Emergency hand pump is also used in case of system failure. |
|
SURFACES |
The conveyor boom is hot dip galvanized. |
|
ELECTRICAL SYSTEM |
Work lamp, standard lighting for chassis, are provided in electrical system. All functions and accessories are controlled from control panels located on the driver’s cluster and on the both sides in the front and rear of the conveyor boom. |
|
OPTIONS |
9000 mm belt length, different capacity of battery pack, forklift pockets, custom painting, logo application, driver’s cabin. |
|
VAN BODY |
The steel constructed body is covered with insulation material filled aluminum plates. The van-body is lifted by a two stage mast lifting system powered by hydraulic cylinders. The van-body provides a lock system for wheelchairs and stretchers. Adequate ventilation is provided inside the van body and windows are provided on the both side walls. |
|
EXTENDABLE FRONT PLATFORM |
The extendable front platform is produced by steel profiles and moves with van body to serve the aircraft. The extendable front platform provides an extension by a hydraulic cylinder. The floor is covered with checkered aluminum. |
|
CHASSIS |
The chassis is designed by Timsan, produced by steel plates and powered by electric traction motors. The unit is stable against wind forces up to 75 km/h. |
|
TRACTION&STEERING SYSTEM |
The traction system is provided by dual direct drive 2x5 kW AC electric motors coupled to planetary wheel hub and powered by 48 V 565 Ah traction battery pack. The electric motors are driven by high efficiency AC controller that enables regenerative braking system. The steering system is controlled by a an electrical system mounted to the steering wheel that controls electric motors which drives the gears of the wheel hub. |
|
CONTROL SYSTEM |
An accelerator and a braking pedal are provided o the driver’s panel which controls the traction system. |
|
HYDRAULIC SYSTEM |
The hydraulic system is provided by an oil tank, hydraulic pump motor, cylinders, lock valves, hydraulic valves, gear type flow divider for stabilizers and some useful accessories. Emergency hand pump is also used in case of engine failure. 4 hydraulic stabilizers are provided for more stability. |
|
SURFACES |
The platform is hot dip galvanized and the other parts are custom painted. |
|
LIGHTING |
4 lighting fixtures and headlamps in front and rear of the platform, gabary lamps at the corners and a beacon are provided on the van body. |
|
OPTIONS |
Canopy for front platform, heating and cooling system for van body, custom painting, logo application. |
|
CHASSIS |
The chassis is produced by steel profiles and steel plates. |
|
STEERING & BRAKING SYS. |
The tow-bar is provided by a fifth wheel system mounted to the chassis for easy steering. Front wheel maneuvering is provided by a slewing ring that works vertically on the axis. The steering system equipped with a brake system that is applied when tow-bar is at upright and released position. |
|
TANK |
The tanks are made of stainless steel and provided by manholes, filler caps and discharge valves. The top of the tanks are covered with anti slip material or steel grid for safe walking. |
|
CLEAN WATER PUMP |
The clean water pump is driven by hydro-motor, which is powered by the diesel engine or electric motor, to be used to pump the clean water to aircraft’s tank. |
|
WASTE WATER COUPLING |
The waste water coupling is made of stainless steel and is of quick coupling type. It is equipped with 4” flexible hose. |
|
CLEAN WATER COUPLING |
The waste water coupling is made of stainless steel and is of quick coupling type. It is equipped with 1” flexible hose. |
|
ELECTRICAL SYSTEM |
The electrical system is powered by a standard battery pack. The electrical system is provided by work lamp and the all accessories are controlled from a control panel. |
|
ELEVATING LADDER |
A foldable ladder is provided to be used for operator to reach desired elevating height to serve aircraft. |
|
SURFACES |
The all parts are custom painted. |
|
OPTIONS |
heating, insulation, vacuum pump, logo application. |
CE certificate of Ambulance Truck
EC Type Examination of Catering Truck
TSE Certificate of Towable Passenger Stairs
TSE Certificate of Lavatory Service Truck
ISO, Parts Manufacturer Approval
Since establishing of the company, Timsan keeps longlife motivation to produce robust, cost-effective and innovative designs for Ground Support Equipment Sector. According to this goal, Timsan expands the product range day by day and nowadays works with massive capability to produce GSE in a wide range.
Timsan focuses on the reliability and safety in all products , besides it ensures the safety of its products with CE compliance. Timsan attains a skillful and experienced R&D team to carry out designs to response market demands of GSE sector and comply CE regulations and to guarantee more safety. All new products are designed and analyzed by this team by using CAD softwares. Meantime this digital ability brings out rapid prototyping and precise designing processes and serves to the primary focus of Timsan which is Research & Devepolment.
Vergi Dairesi : SULTANBEYLİ
Vergi Numarası : 844 003 8181
Kuruluş Tarihi : 5 Mayis 1982
İTO Sicil No : 187614
Taahhüt/Ödenen sermaye :5.000.000 / 5.000.000
